Sale!

LX TDA50 Circulation Pump 0.5HP

Original price was: £151.70.Current price is: £106.99.

In stock

SKU: SPPULX-CIR-T05001 Categories: , Tags: , ,

Description



Model:LX TDA50 Circulation Pump 0.5HPLX TDA75 Circulation Pump 0.75HPLX TDA100 Circulation Pump 1.0HPLX TDA200 Circulation Pump 2.0HP
Type of product:Circulation pumpCirculation pump / filter pumpWater pump / Jet pump
Manufacturer / model:LX TDA50LX TDA75LX TDA100LX  TDA200
Frame:48
Common Power reference:1/2HP3/4HP1 HP2.0 HP
Power:Volts:230
Hz:50
Motor KW:0.37
Motor HP:0.5
Wet end impellor HP:0.5
Amps:2.0
RPM:2900
Capacitor:7uF
Volts:230
Hz:50
Motor KW:0.55
Motor HP:0.75
Wet end impellor HP:0.75
Amps:3.2
RPM:2900
Capacitor:10uF
Volts:230
Hz:50
Motor KW: 0.75
Motor HP:
1HP
Wet end impellor HP:
Amps:3
.8
RPM:2900
Capacitor:15uf
Volts:230
Hz:50
Motor KW:1.5
Motor HP:2.14
Wet end impellor HP:
Amps:
7
RPM:2900
Capacitor:25uf
Plumbing connections:1.5 inch
Electrical connections:Comes with plain cable attached
Overall outer dimensions
and widest and tallest points:
Length:320mm
Height:190mm
Depth:160mm
Length:350mm
Height:205mm
Depth:160mm
Length:350mm
Height:190mm
Depth:140mm
Weight:8550g
Length:400mm
Height:205mm
Depth:175mm
Found on hot tubs such as:Chinese Spas amongst othersChinese Spas amongst others
Ideal replacement for:Rocoi LDPB-140B
Chinese Spas, AMC Winer Spas, Trinity E-Zone, Monalisa, Cascade Spas
Additional notes:Unions included
Closest match for JA50
Unions includedWe have also sold a fair few of these to people with Whirlpool Baths that use an air switch facility. If you also purchase a TBS106A air switch (our code AS-TA106)you can install this, interrupting the in coming live wire through the air switch.
This pump is the same as the DXD pump and EA350 pump also found on the market, check watts or amp draw to be certain or call us.
Optional air switch, you can take the air switch out if you do not want to use it, or you can just leave it permanently on. As seen in this picture, this pump is mainly used as a booster pump but is also used as a circulation pump in some Chinese Hot Tub models.
